Neon Flex
AQS-500
IP68 Neon Flex
Introduction
AQS-500 is a high output top-view IP68 Neon Flex. Use for external facade illumination, pool copings, in-pavement channels and exterior wall grazing where substantial moisture and mechanical protection is required.
Specifications
AQS-500
Neon Flex
Strip Lighting
24V DC
5W / 12W / 17W / 18W
IP68
20lm - 1191lm (see datasheets)
2200K / 2700K / 3000K / 3500K / 4000K / 4500K / 5000K / 6500K / RGB / RGBW / COLOURS
Constant Voltage (PWM) / DMX / Direct DMX UCS512EH
8m / 10m / 15m
10m / 20m / 30m
100mm / 166.7mm
Horizontally
80mm
SMD3528 / SMD5050
60pcs / 70pcs / 72pcs
70000 Hours L70 at 25°C, 50000 Hours L70 at 50°C
Eco PVC
120°
-20° to +40°C
5° to +35°C
3 Year Aqualux Warranty
AQS-500
Configure order code
AQS-500
To configure your product/s, select from the options below.
Multiple selections are possible to produce your downloadable datasheet/s.
AQS-500 - has 12 variations
Product Code
Downloads
CCT
Power Input
Watts/M
Lumen Output
CRI
Max Length
Cut Interval
Downloads
AQS-500-27A05
2700K
24V DC
5W pm
160lm
90 CRI
15m
166.7mm
AQS-500-27A12
2700K
24V DC
12W pm
160lm
90 CRI
15m
166.7mm
AQS-500-27A18
2700K
24V DC
18W pm
160lm
90 CRI
15m
166.7mm
AQS-500-27A17
2700K
24V DC
17W pm
160lm
90 CRI
15m
166.7mm
AQS-500-30A05
3000K
24V DC
5W pm
160lm
90 CRI
15m
166.7mm
AQS-500-30A12
3000K
24V DC
12W pm
160lm
90 CRI
15m
166.7mm
AQS-500-30A18
3000K
24V DC
18W pm
160lm
90 CRI
15m
166.7mm
AQS-500-30A17
3000K
24V DC
17W pm
160lm
90 CRI
15m
166.7mm
AQS-500-40A05
4000K
24V DC
5W pm
160lm
90 CRI
15m
166.7mm
AQS-500-40A12
4000K
24V DC
12W pm
160lm
90 CRI
15m
166.7mm
AQS-500-40A18
4000K
24V DC
18W pm
160lm
90 CRI
15m
166.7mm
AQS-500-40A17
4000K
24V DC
17W pm
150lm
90 CRI
10m Single
166.7mm
To configure your product/s, select from the options below.
Multiple selections are possible to produce your downloadable datasheet/s.
AQS-500 - has 12 variations
| Product Code | Downloads | CCT | Power Input | Watts/M | Lumen Output | CRI | Max Length | Cut Interval | Downloads | |
|---|---|---|---|---|---|---|---|---|---|---|
| AQS-500-27A05 | 2700K | 24V DC | 5W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-27A12 | 2700K | 24V DC | 12W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-27A18 | 2700K | 24V DC | 18W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-27A17 | 2700K | 24V DC | 17W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-30A05 | 3000K | 24V DC | 5W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-30A12 | 3000K | 24V DC | 12W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-30A18 | 3000K | 24V DC | 18W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-30A17 | 3000K | 24V DC | 17W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-40A05 | 4000K | 24V DC | 5W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-40A12 | 4000K | 24V DC | 12W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-40A18 | 4000K | 24V DC | 18W pm | 160lm | 90 CRI | 15m | 166.7mm | |||
| AQS-500-40A17 | 4000K | 24V DC | 17W pm | 150lm | 90 CRI | 10m Single | 166.7mm |
