AGL-200
Accessories · Globe
Accessories
AGL-200
3W LED Globe G4
The AGL-200 series of 3w LED drop-in lamps are the perfect globes for any G4 BIPIN application, whether it be indoor or outdoor. See datasheets for full electrical, mechanical, and photometric data.
Available Downloads
Dimension
SPECIFICATIONS
| Product Code | AGL-200 |
| Description | Aqualux 200 Series LED Lamp |
| Type | G4 BIPIN |
| Construction | Clear Siliicone |
| Warranty | 3 Year Aqualux Warranty |
| Country of Manufacture | Australia |
| Input Voltage Range | 12~24V AC/DC |
| Nominal Voltage | 24VAC |
| Nominal Power | 3W |
| Nominal Current | 125mA |
| Input Voltage | 24VDC / 24VAC |
| Rated Power | 2.5 / 2.4 |
| Operating Frequency | 50Hz (24VAC) |
| Dimming Compatibility | Non-Dimming |
| Wiring Scheme | Parallel |
| Startup Time | < 0.5s |
| Overall Length | 42mm |
| Max Diameter | 16mm |
| Lamp Base | G4 |
| Weight | 8g |
| Operating Temp Range | -20° - 45° |
| IP Rating | IP65 |
| Nominal Flux (lm) | 200 |
| Input Voltage | 24VAC |
| Input Power (W) | 2.4 |
| Rated Flux (lm) | 216 - 242 |
| Efficacy (lm/W) | 88.76 - 98.47 |
| CCT | 2700K / 3000K |
| CCT Description | Warm White |
| CRI (Ra) | 85 |
| CRI (R9) | 17 - 23 |
| TM-30 (Rf) | 85 |
| TM-30 (Rg) | 92 - 94 |
| SDCM | - |
| Peak Intensity (cd) | 21 - 25 |
| Nominal Beam Angle | 360° |
| Measured Beam Angle (FWHM) | 360° |
| AS/NZS 62838:2020 | Yes |
| AS/NZS CISPRO 15: 2018 | Yes |
| EMI | Yes |
| RCM | N/A |
| Mercury Content | 0mg |
| L70 | 25,000h |
| Switching Cycles | 15,000 |
