AGL-250
Accessories · Globe
Accessories
AGL-250
LED Globe
The Aqualux AGL-250 series is an advanced 4W MR16 LED "drop-in" globe explicitly engineered for outdoor landscape lighting.
Its standout feature is its 12V–24V AC/DC multi-voltage capability. In landscape lighting, long cable runs often cause a "voltage drop," which makes standard 12V lights at the end of a line appear noticeably dimmer than those at the start.
Available Downloads
Dimension
SPECIFICATIONS
| Product Code | AGL-250 |
| LED Colour | R / G / B / Amber |
| Type | MR16 GU5.3 |
| Construction | Luxeon LXZ1 |
| Warranty | 3 Year Aqualux Warranty |
| Country of Manufacture | China |
| Input Voltage Range | 12~24V AC/DC |
| Nominal Power | 4W |
| Nominal Current | 167-333 mA |
| Rated Power | 4W |
| Max. no. of lamps on AQD24-040 | 10 (12VDC) / 10 (24VDC) |
| Max. no. of lamps on AQD24-100 | 25 (12VDC) / 25 (24VDC) |
| Dimming Compatibility | Non-dimmable |
| Wiring Scheme | Parallel |
| Startup Time | < 0.5s |
| Overall Length | 47mm |
| Max Diameter | 50mm |
| Lamp Base | GU5.3 |
| Weight | 55g |
| Operating Temp Range | 20° - 45° |
| IP Rating | IP20 |
| Nominal Flux (lm) | 250 |
| Rated Flux (lm) | 235-250 |
| Efficacy (lm/W) | 62.5 |
| CCT | R / G / B / 3000K (30X10 Only) |
| CRI (Ra) | 83 |
| TM-30 (Rf) | 80 to 82 |
| TM-30 (Rg) | 92 - 97 |
| Peak Intensity (cd) | 550 |
| Nominal Beam Angle | 10° - 38° |
| Measured Beam Angle (FWHM) | 10° - 38° |
| EMI | Yes |
| RCM | N/A |
| Mercury Content | 0mg |
| L70 | 30,000h |
| Switching Cycles | 15,000 |
