AQL-154

Low glare inground uplight designed for uplighting where glare control is a priority.

The AQL-154 is an inground uplight featuring a deeply recessed light source for discrete illumination. It is designed for uplighting applications where glare control is a priority.

CNC machined from 6000 series aluminium or brass, this IP65-rated fixture features anti-siphon cabling. Technical specifications include 24V DC control gear, 15-degree or 30-degree optics, and 4W or 10W LED light sources.

Available Downloads

Dimension

SPECIFICATIONS

Product Code	AQL-154
Construction	CNC Machined Aluminium
Warranty	7 Years
Country of Manufacture	Australia

Voltage	24V DC
Frequency	-
Flicker free	Yes.
Dimming	Yes. Direct PWM.
Max. qty of fixtures C16 Breaker	PSU Dependant

CRI (3000K)	90+
SDCM	3

LED Lifetime	L80 B10 70,000h (Ta 25C)
Operating temperature range	0C - 40C
IP Rating	IP65
IK Rating	IK04
Weight	0.2kg
Power cable	2-Core Anti-Siphon Cable
Electrical insulation class	Class II

Compliance / Certifications	SELV
Environmental certifications	IP IK
