AQL-510
Lights · Wall Light
Lights
AQL-510
Angled solid cast brass LED step light designed for pathway lighting.
The AQL-510 is an LED step and wall light designed for pathway illumination. It projects light outward at an angle to maximize illumination on walkways rather than the wall surface.
Built from solid cast brass with an IP65 rating, this fixture features a 4W, 400lm LED source in 2700K, 3000K, or 4000K. It includes a frosted diffuser, 24V DC control gear, and five finish options.
Available Downloads
Dimension
SPECIFICATIONS
| Product Code | AQL-510 |
| Construction | Brass |
| Warranty | 7 Years |
| Country of Manufacture | Australia |
| CRI (3000K) | 90+ |
| SDCM | 3 |
| Compliance / Certifications | SELV |
| Environmental certifications | IP IK |
| Voltage | 24V DC |
| Frequency | - |
| Flicker free | Yes. |
| Dimming | Yes. Direct PWM. |
| Max. qty of fixtures C16 Breaker | PSU Dependant |
| LED Lifetime | L80 B10 70,000h (Ta 25C) |
| Operating temperature range | 0C - 40C |
| IP Rating | IP65 |
| IK Rating | IK04 |
| Weight | 0.2kg |
| Power cable | 2-Core Anti-Siphon Cable |
| Electrical insulation class | Class II |
