AQL-881

Highly configurable wall mount downlight designed for architectural and commercial applications.

The AQL-881 is a surface-mounted wall downlight designed for architectural and commercial applications. It offers ultra-low glare or high-efficiency reflector optics, with light source options including RGBW, 98CRI, and 2200K.

CNC machined from 6000 series aluminium, this IP65-rated fixture features a terminal block connection. It supports 24V DC, 240V DALI, or PWM dimming, and is finished in Dulux powder coat.

Available Downloads

Dimension

SPECIFICATIONS

Product Code	AQL-881
Construction	Brass
Warranty	7 Years
Country of Manufacture	Australia

CRI (3000K)	90+
SDCM	3

Compliance / Certifications	SELV
Environmental certifications	IP IK

Voltage	24V DC
Frequency	-
Flicker free	Yes.
Dimming	Yes. Direct PWM.
Max. qty of fixtures C16 Breaker	PSU Dependant

LED Lifetime	L80 B10 70,000h (Ta 25C)
Operating temperature range	0C - 40C
IP Rating	IP65
IK Rating	IK04
Weight	0.2kg
Power cable	2-Core Anti-Siphon Cable
Electrical insulation class	Class II
