AQS-180-ULTRA
Strip Lighting · High Performance Strip
Strip Lighting
AQS-180-ULTRA
AQS-180-Ultra
AQS-180 is a high-output, ultra-efficient 2835-based LED Strip. Used for internal illumination, the AQS-180 features 90+ CRI, < 3 SDCM for consistent appearance and a heavy-duty 3 OZ Copper base for improved heat management.
Available Downloads
Dimension
SPECIFICATIONS
| Product Code | AQS-180 |
| Cut Interval | 29.4mm |
| Bend Direction | Vertically |
| Minimum Bend Diameter | 50mm |
| Materials | 3M Adhesive Backing |
| Warranty | 5 Year Aqualux Warranty (Must be mounted in Aluminium Extrusion) |
| Country of Manufacture | China |
| LED Type | COB |
| LED Qty / M | 272pcs |
| CCT & Colour Options | 2000K / 2700K / 3000K / 4000K |
| CRI | 90+ |
| Emission Angle | 180° |
| Lumen Maintenance | 50,000 Hours L70 @ 30°C |
| 2000K / 20W | 2220lm |
| 2700K / 20W | 3180lm |
| 3000K / 20W | 3200lm |
| 4000K / 20W | 3320lm |
| Voltage | 24V DC |
| Watts (per Meter) | 20W |
| Working Mode | Constant Voltage (PWM) / DMX |
| Max Length (Single Power Feed) | 5m |
| Max Length (Double Power Feed) | 10m |
| Operating Temperature | -20° to +40°C |
| Installation Temperature | 5° to +35°C |
| IP Rating | IP20 |
