AQS-401
Neon Flex · Top Bend
Neon Flex
AQS-401
IP65 Neon Flex
The AQS-401 Neon Flex product is manufactured in a continuous extrusion process and then manually terminated to length with IP65 overmolded cable entry points here in our Sydney factory for a quicker turn-around time.
Available Downloads
Dimension
SPECIFICATIONS
| Product Code | AQS-401-Mono |
| Cut Interval | 35.7mm |
| Bend Direction | Vertically |
| Minimum Bend Diameter | 80mm |
| Materials | Silicone |
| Warranty | 3 Year Aqualux Warranty - Not for pools or pool copings |
| Country of Manufacture | China |
| LED Type | 2835 |
| LED Qty / M | 168pcs |
| CCT & Colour Options | 2700K / 3000K / 4000K / 5000K / (2700K stocked) |
| Emission Angle | 180° |
| Lumen Maintenance | 70,000 Hours L70@ 25°C, 50,000 Hours L70@ 50°C |
| 2700K / 5W | 380lm |
| 2000K / 10W | 320lm |
| 3000K / 5W | 400lm |
| 2700K / 10W | 730lm |
| 3000K / 10W | 780lm |
| 4000K / 10W | 820lm |
| 5000K / 10W | 830lm |
| 6500K / 10W | 828lm |
| Voltage | 24V DC |
| Watts (per Meter) | 5W / 10W |
| Working Mode | Constant Voltage (PWM) / DMX |
| Max Length (Single Power Feed) | 10m (5W) / 7m (10W) |
| Max Length (Double Power Feed) | 20M (5W) / 14M (10W) |
| Operating Temperature | -20° to +40°C |
| Installation Temperature | 5° to +35°C |
| IP Rating | IP65 |
