AQS-420
Neon Flex · Side Bend
Neon Flex
AQS-420
IP65 Neon Flex
The AQS-420 Neon Flex product is manufactured in a continuous extrusion process and then manually terminated to length with IP65 overmolded cable entry points here in our Sydney factory for a quicker turn-around time.
Available Downloads
Dimension
SPECIFICATIONS
| Product Code | AQS-420-Mono / RGBW |
| Cut Interval | 50mm / 71.4mm |
| Bend Direction | Horizontally |
| Minimum Bend Diameter | 120mm |
| Materials | Silicone |
| Warranty | 3 Year Aqualux Warranty - Not for pools or pool copings |
| Country of Manufacture | China |
| LED Type | SMD2835 |
| LED Qty / M | 140pcs / 196pcs |
| CCT & Colour Options | 2700K / 3000K / 4000K / 5000K / RGBW |
| Emission Angle | 120° |
| Lumen Maintenance | 70,000 Hours L70@ 25°C, 50,000 Hours L70@ 50°C |
| 2000K / 10W | 270lm |
| 2000K / 15W | 450lm |
| 2700K / 10W | 300lm |
| 2700K / 15W | 460lm |
| 3000K / 10W | 330lm |
| 3000K / 15W | 470lm |
| 4000K / 10W | 340lm |
| 4000K / 15W | 500lm |
| 5000K / 10W | 345lm |
| 5000K / 15W | 525lm |
| RGB / 18W | 300lm |
| RGBW / 15W | 300lm |
| Voltage | 24V DC |
| Watts (per Meter) | 10W / 15W |
| Working Mode | Constant Voltage (PWM) / DMX |
| Max Length (Single Power Feed) | 10m (10W) / 7m (15W) |
| Max Length (Double Power Feed) | 20m (10W) / 14m (15W) |
| Operating Temperature | -20° to +40°C |
| Installation Temperature | 5° to +35°C |
| IP Rating | IP65 |
